Heat Shrink Wrap PVC
Heat Shrink Wrap PVC
Heat Shrink Wrap PVC from Marsen Energy is a high-quality Shrink Wrap it is designed for insulating and protecting battery packs and electrical assemblies. Sold by the metre, this heat shrink is available in a wide range of widths to suit small to large battery builds.
Made from durable, flexible PVC, it provides a professional finish and secure insulation when heated. Whether you’re building DIY lithium-ion packs or bundling cables, this is an essential material for clean, safe work.
Available Widths (Flat Width):
65mm | 90mm | 120mm | 135mm | 150mm | 160mm | 170mm | 180mm | 190mm | 200mm | 220mm | 230mm | 250mm | 280mm | 300mm | 350mm
Colours:
-
All widths available in Blue
-
150mm and 250mm also available in Black
Features:
-
Material: Durable, flexible PVC
-
Length: Sold by the metre (multiple metres will be supplied in a continuous length)
-
Application: Suitable for battery packs, cable management, and electronics
-
Finish: Glossy professional look
Need help choosing the right size for your battery? See size guide here
Sold by the metre. Bulk discounts automatically applied at checkout:
• 5–10 metres: 10% off
• 11–20 metres: 15% off
• 21 metres and over: 20% off
Price range: $8.50 through $21.00
Specifications
- Heat Shrink Wrap PVC per metre
- Shrinkage temperature: 80 ° C
- Temperature range: -40 ° C to 105 ° C
- Rated voltage: 300v
- Product colour: blue
- Product features: excellent environmental protection, insulation, stable performance, low shrinkage temperature, fast shrinkage
- Uses: Aluminum, electrolytic capacitors, batteries, lithium battery packs, electronic components, lighting, LEDs, etc., for aesthetic reasons
- Heat preservation and moisture, corrosion and dust prevention
- A heat gun or other heat source can be used for shrinking
- Click here for measurement calculator
Applications
How to choose the size:
- If you want to convert flat width to diameter measurement, multiply flat width by 2/pi.
- To convert flat width to circumference, multiply by 2.
- The circumference is what you use to compare the circumference of the item you want to wrap. You will need a circumference of heat shrink larger than the circumference of the item.
- You can use larger heat shrink because of the large shrinkage ratio of PVC heat shrink. Slowly apply heat due to the low melting temperature of PVC.
- For help with size requirement view Heat Shrink Wrap MeasurementsÂ
